360° Rotary High Speed Cylinder Inkjet Bottle Printer for Cups and Cans
Product Overview
This high-performance cylinder inkjet printer delivers exceptional printing quality on bottles, cups, cans, and other cylindrical objects with 360° coverage and high-speed operation.
Key Features
- High Precision: 3.5pl droplet size provides optimal balance between throughput and print quality for various applications
- High Resolution: Multiple inkjet schemes available for different printing materials with accurate colors, distinct layers, and uniform transitions
- Intelligent Maintenance: Automatic nozzle flashing and moisture retention during non-working periods prevents ink curing and blockages
Technical Specifications - CF-2510 (Duplex)
| Specification |
Details |
| Nozzle Selection |
Ricoh GEN 5i |
| Print Size |
235cm × 63.2cm |
| Printing Height |
0-15cm (Customizable) |
| Equipment Size |
412cm × 159cm × 144cm |
| Equipment Weight |
860kg |
| Printing Software |
Photoprint / PrintFactory |
| Ink Type |
LED Environmental Protection UV Ink |
| Ink Colors |
W+CMYK+Varnish |
| Maximum Power |
3000W |
| Effective Orifice |
1280 |
| Ink Drop Volume |
3.5PL |
| Nozzle Length |
27MM |
| Single Nozzle Color |
4 |
| Rated Voltage |
240V 50/60HZ |
Manufacturer Profile
Guangzhou Skydeekenutek Co., Ltd. specializes in distribution and wholesale of UV printers, including single-pass UV printers, UV flatbed printers, UV mesh belt printers, banner printers, and crystal label printers.
Our 2500 m² factory located in Panyu, Guangzhou, Guangdong Province employs over 10 R&D staff and 150 workers. We maintain ISO certification with strict quality control and production management systems. We support OEM and ODM services with over 10 years of UV printer manufacturing experience, receiving positive feedback from clients worldwide.
We export to France, Germany, Vietnam, India, and other countries, with products holding CE and RoHS certifications.
Packaging & Shipping
Certifications
Frequently Asked Questions
Q1: Do I need white ink and varnish ink?
White ink enables high-quality graphics on various materials by serving as a primer for non-white substrates. Varnish enhances print brightness and extends UV ink fade resistance.
Q2: What materials can UV flatbed printers print on?
UV printers handle all flatbed media including PP/PVC boards, KT boards, acrylic, plexiglass, metal, tiles, phone cases, wood boards, and more. They eliminate the need for coating and prevent fading and blistering issues.
Q3: Which languages does the RIP installation interface support?
Korean, German, French, Finnish, Dutch, Portuguese, Japanese, Spanish, Italian, English, Simplified Chinese, and Traditional Chinese.
Q4: How is the after-sales service?
Our experienced technicians provide comprehensive technical support, including operational training until full proficiency is achieved. International technical support and on-site service are available when needed.
Q5: Regarding printer maintenance
We recommend daily ink purging when starting the printer. For periods of non-use exceeding 10 days, clean the print head with cleaning fluid and maintain nozzle moisture.
Q6: Are you a factory or a foreign trade company?
We are a manufacturing factory, enabling us to offer competitive pricing and high-quality services directly.
